Acerca del producto
24× Gigabit Ports (16× PoE+), 4× Gigabit SFP Slots
150 W Total PoE Budget
Fanless Design for Silent Operation
Zero-Touch Provisioning
Centralized Management
Omada App
Static Routing
Traffic Separation
Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.
Multiple Application Scenarios |Surveillance
Works with IP Cameras
Conference Call
Works with IP Phones
Wi-Fi Coverage
Works with Access Points
Wired Connections
Works with Non-PoE Devices such as PCs and Printers
- Gigabit Ethernet port for ultra-fast network speeds
- Rack mounting enables you to organize wires & secure cables for professional installation
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Quickly and easily set up a wired network with 24 networking ports
Especificaciones técnicas
| I/O Expansions | |
| Expansion Slot Type | SFP (mini-GBIC) |
| Number of SFP Slots | 4 |
| Total Number of Expansion Slots | 4 |
| Technical Information | |
| Features | Zero-Touch Provisioning (ZTP) |
| Fanless | |
| DHCP Snooping | |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T |
| 1000Base-X | |
| Ethernet Technology | Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| Optical Fiber | |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Total Number of Network Ports | 24 |
| Port/Expansion Slot Details | 4 x Gigabit Ethernet Expansion Slot |
| 16 × Gigabit Ethernet PoE+ | |
| 8 x Gigabit Ethernet Network | |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Height | 1.70" (43.18 mm) |
| Width | 17.30" (439.42 mm) |
| Depth | 8.70" (220.98 mm) |
| Compatible Rack Unit | 1U |
| Product Material | Metal |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | SG2428LP |
| Manufacturer Website Address | http://www.tp-link.com |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Product Model | SG2428LP |
| Product Name | Omada 28-Port Gigabit Smart Switch with 16-Port PoE+ |
| Product Line | Omada |
| Brand Name | TP-Link |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3af |
| IEEE 802.3at | |
| IEEE 802.3x | |
| IEEE 802.1ab | |
| IEEE 802.1p | |
| IEEE 802.1Q | |
| IEEE 802.1x | |
| Power Description | |
| Input Voltage | 230 V AC |
| 120 V AC | |
| Power Source | Power Supply |
| Frequency | 50 Hz |
| 60 Hz | |
| Power Consumption | 184.70 W |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 150 W |
| Miscellaneous | |
| Application/Usage | Network |
| IP Phone | |
| IP Camera | |
| Printer | |
| Surveillance | |
| Wireless Access Point | |
| Desktop | |
| Package Contents |
|
| Certifications & Standards |
|
