Acerca del producto
- 4× 10 Gbps SFP+ Slots
- 24× Gigabit PoE+ Ports
- 384 W Total PoE Budget
- Centralized Management
- Omada App
- Zero-Touch Provisioning
- Ethernet Ring
- Protection Switching
- Static Routing
Easily Build a Whole 10G Multi-gigabit Network | 10G Router
Ensures the fast way
Full 10G Fiber Switch
Lightning-fast aggregation switching
Switch with 10G Uplink
PoE Switch with 10G Uplink
Wi-Fi 7/6 APs with 10G/2.5G Ports
Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.
Multiple Application Scenarios | Surveillance
Works with IP Cameras
Conference Call
Works with IP Phones
Wi-Fi Coverage
Works with Access Points
Wired Connections
Works with Non-PoE Devices such as PCs and Printers
- Gigabit Ethernet port for ultra-fast network speeds
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Quickly and easily set up a wired network with 24 networking ports
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 24 ports
Especificaciones técnicas
| Management & Protocols | |
| Manageable | Yes |
| Technical Information | |
| Features | Zero-Touch Provisioning (ZTP) |
| I/O Expansions | |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 4 |
| Total Number of Expansion Slots | 4 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Total Number of Network Ports | 24 |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet PoE+ |
| 4 x 10 Gigabit Ethernet Expansion Slot | |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T |
| 10GBase-X | |
| Ethernet Technology | Gigabit Ethernet |
| 10 Gigabit Ethernet | |
| Media Type Supported | Optical Fiber |
| Twisted Pair | |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Desktop | |
| Height | 1.70" (43.18 mm) |
| Width | 17.30" (439.42 mm) |
| Depth | 13" (330.20 mm) |
| Product Material | Metal |
| Miscellaneous | |
| Application/Usage | Network |
| IP Phone | |
| IP Camera | |
| PC | |
| Wireless Access Point | |
| Printer | |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | SG3428XMP |
| Manufacturer Website Address | http://www.tp-link.com |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Product Model | SG3428XMP |
| Product Name | Omada SG3428XMP Ethernet Switch |
| Product Line | Omada |
| Brand Name | TP-Link |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Power Source | Power Supply |
| Frequency | 60 Hz |
| 50 Hz | |
| Power Consumption | 486.20 W |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 384 W |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.1x |
| IEEE 802.3af | |
| IEEE 802.3ah | |
| IEEE 802.1Q | |
| IEEE 802.3x | |
| IEEE 802.3at | |
| IEEE 802.1p | |
| IEEE 802.1ab |
