CONMUTADOR ADMINISTRADO OMADA DE 24 PUERTOS GIGABIT Y 4 PUERTOS 10GE SFP+ L2+ CON

CONMUTADOR ADMINISTRADO OMADA DE 24 PUERTOS GIGABIT Y 4 PUERTOS 10GE SFP+ L2+ CON

Precio habitual $648.83 CAD
Precio habitual $778.59 CAD Precio de oferta $648.83 CAD
-16% OFF Agotado
Los gastos de envío se calculan en la pantalla de pago.
Switch gestionable TP-Link de 24 puertos Gigabit y 4 puertos 10GE SFP+ L2+ con 16 puertos PoE+ y 8 puertos PoE++ - 24 puertos - Gestionable - Gigabit Ethernet, 10 Gigabit Ethernet - 10/100/1000Base-T, 1000Base-X, 10GBase-X - Compatible con 2 capas - Consumo de energía de 605,50 W - Presupuesto PoE de 500 W - Par trenzado, fibra óptica - Puertos PoE - 1U - Montaje en rack

VPN: SG3428XMPP SKU: 122537NDS UPC: 810142820400

  • 4 ranuras SFP+ de 10 Gbps
  • 8 puertos Gigabit 802.af/at/bt PoE++ (presupuesto máximo de PoE de 90 W para cada puerto)
  • 16 puertos Gigabit 802.3af/at PoE+ (presupuesto máximo de 30 W para cada puerto)

Bloque de texto

Descuento por volumen disponible: solicite cotización.

Ver todos los detalles

Recently Viewed

CONMUTADOR ADMINISTRADO OMADA DE 24 PUERTOS GIGABIT Y 4 PUERTOS 10GE SFP+ L2+ CON

Resumen de información del producto

CONMUTADOR ADMINISTRADO OMADA DE 24 PUERTOS GIGABIT Y 4 PUERTOS 10GE SFP+ L2+ CON

Acerca del producto

TP-Link | Omada L2+ managed switches provide high performance, powerful L2 and L2+ features like static routing, enterprise-level QoS, advanced security strategies and a bundle of ISP features. The 10-gigabit ports ensure high-speed data transfer, and their backward compatility with gigabit products reserves room for network upgrades, therefore guarantees stable and long-term usability. The IP-MAC-Port Binding (IMPB) and Access Control List (ACL) functions protect against broadcast storm, ARP and Denial-of-Service (DoS) attacks, etc. Quality of Service (QoS, L2 to L4) provides enhanced traffic management capabilities to move your data smoother and faster. The OAM function helps facilitate network management. Moreover, the easy-to-use web management interfaces, along with CLI, SNMP and Dual Image mean faster setup and configuration with less downtime. TP-Link | Omada L2+ 10-gigabit managed switches provide a reliable, secure solution for enterprise, campus and ISP networks.



Software Defined Networking (SDN) with Cloud Access

Omada Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network--all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.



Hassle-Free Centralized Cloud Management

100% centralized cloud management of the whole network from different sites - all controlled from a single interface anywhere, anytime.



Assign Different Management Roles

Multi-user privilege assignment is available to increase management efficiency and security. Multi-person management, multi-level permissions, and the ability to add admins as needed, enable flexible network operation and maintenance.



Easy and Intelligent Network Monitoring

Comprehensive Protection for the Whole Network The easy-to-use dashboard makes it easy to see your real-time network status; check network usage and traffic distribution; receive network condition logs, abnormal event warnings, and notifications; or even track key data for better business results. Network topology helps admins quickly see and troubleshoot connections at a glance.

  • 4× 10 Gbps SFP+ slots
  • 8× Gigabit 802.af/at/bt PoE++ ports (Max 90 W PoE budget for each port)
  • 16× Gigabit 802.3af/at PoE+ ports (Max 30 W budget for each port)
  • 500 W total PoE budget*
  • Centralized cloud management via the web or the Omada app
  • Standalone management via web, CLI, SNMP, and RMON
  • Static Routing, VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM
  • ERPS supports rapid protection and recovery in a ring topology
  • Durable metal casing and rack-mountable design

Especificaciones técnicas

Management & Protocols
ManageableYes
Reliability
MTBF292830 Hour
I/O Expansions
Expansion Slot TypeSFP+
Number of SFP+ Slots4
Total Number of Expansion Slots4.0
Physical Characteristics
Form FactorRack-mountable
Length17.30" (439.42 mm)
Height1.70" (43.18 mm)
Depth13" (330.20 mm)
Compatible Rack Unit1U
Product MaterialMetal
Interfaces/Ports
Network (RJ-45)Yes
Total Number of Network Ports24
Port/Expansion Slot Details16 x 10/100/1000BASE-T Gigabit Ethernet PoE+ RJ-45 Network Port
1 x Micro-USB Console Port
1 x RJ45 Console Port
4 x 1/10 Gigabit Ethernet SFP+ Expansion Slot
8 x 10/100/1000BASE-T Gigabit Ethernet PoE++ RJ-45 Network Port
General Information
Product TypeEthernet Switch
Manufacturer Part NumberSG3428XMPP
Manufacturer Website Addresshttp://www.tp-link.com
ManufacturerTP-LINK Technologies Co., Ltd
Product ModelSG3428XMPP
Product Name24-Port Gigabit and 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ & 8-Port PoE++
Product LineOmada
Brand NameTP-Link
Media & Performance
Network Technology10GBase-X
10/100/1000Base-T
1000Base-X
Maximum Data Transfer Rate1.25 GB/s
Ethernet TechnologyGigabit Ethernet
10 Gigabit Ethernet
Media Type SupportedTwisted Pair
Optical Fiber
Power Description
Input Voltage230 V AC
120 V AC
Power SourcePower Supply
Frequency50 Hz
60 Hz
Power Consumption605.50 W
PoE (RJ-45) PortYes
PoE Budget500 W
Miscellaneous
Application/UsagePrinter
PC
Office
Retail
Enterprise
IP Camera
Education
Network
Security
Wireless Access Point
IP Phone
Campus
Network & Communication
Layer Supported2
Networking StandardsIEEE 802.3i
IEEE 802.3u
IEEE 802.3x
IEEE 802.3z
IEEE 802.3bt
IEEE 802.3at
IEEE 802.3ah
IEEE 802.3af
IEEE 802.3ae
IEEE 802.3ad
IEEE 802.1x
IEEE 802.1w
IEEE 802.1Q
IEEE 802.1p
IEEE 802.1D
IEEE 802.1ab
IEEE 802.1s
IEEE 802.3ab
