Acerca del producto
- 24× Gigabit RJ45 ports and 4× 10 Gbps SFP+ slots
- 128 Gbps switching capacity per unit
- Physical stacking for built-in redundancy and performance
- L3 features: RIP, OSPF, ECMP, VRRP, PIM-DM, DHCP Server/Relay
- Security Strategies: ACL, Port Security, DoS Defend, 802.1X
- Highly Available with two internal fixed power supplies, VRRP, and ERPS
- Centralized cloud management via the Omada SDN controller
- Standalone management via web, CLI, SNMP, and RMON
- With Ethernet connections, give your home or small office network speeds of up to 10mbps per port
- Managed switch provides a reliable foundation for your network
- Management capability provides control over setup and configuration of your network
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Stack port provides an easy and hassle-free way to extend your office network
- Quickly and easily set up a wired network with 24 networking ports
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 24 ports
Especificaciones técnicas
| Management & Protocols | |
| Manageable | Yes |
| Network & Communication | |
| Networking Standards | IEEE 802.1p |
| Miscellaneous | |
| Application/Usage | Business |
| Enterprise | |
| I/O Expansions | |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 4 |
| Total Number of Expansion Slots | 4.0 |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Height | 1.70" (43.18 mm) |
| Width | 17.30" (439.42 mm) |
| Depth | 15" (381 mm) |
| Compatible Rack Unit | 1U |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T |
| 10GBase-X | |
| Maximum Data Transfer Rate | 1.25 GB/s |
| Ethernet Technology | 10 Gigabit Ethernet |
| Ethernet | |
| Media Type Supported | Optical Fiber |
| Twisted Pair | |
| General Information | |
| Product Type | Layer 3 Switch |
| Manufacturer Part Number | SG6428X |
| Manufacturer Website Address | http://www.tp-link.com |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Product Model | SG6428X |
| Product Name | Omada 24-Port Gigabit Stackable L3 Managed Switch with 4 10G Slots |
| Product Line | Omada |
| Brand Name | TP-Link |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Power Source | Power Supply |
| Frequency | 60 Hz |
| 50 Hz | |
| Power Consumption | 28.40 W |
| Number of Power Supplies Installed | 2 |
| PoE (RJ-45) Port | Yes |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Stack Port | Yes |
| Total Number of Network Ports | 24 |
| Port/Expansion Slot Details | 4 × 10G SFP+ Expansion Port |
| 24 × 10/100/1000BASE-T RJ45 Network Ports | |
| 2 × USB 2.0 Ports | |
| 1 × RJ45 Management Port | |
| 1 × RJ45 Console Port |
