Tripp Lite SmartPro SMART2200RM2U UPS de 2200 VA para montaje en rack - 2200 VA/1

Tripp Lite SmartPro SMART2200RM2U UPS de 2200 VA para montaje en rack - 2200 VA/1

Precio habitual $1,890.95 CAD
Precio habitual $2,269.14 CAD Precio de oferta $1,890.95 CAD
-16% OFF Agotado
Los gastos de envío se calculan en la pantalla de pago.
UPS SmartPro SMART2200RM2U de Tripp Lite, 2200 VA, para montaje en rack - 2200 VA/1920 W - Carga completa en 5 minutos - 4 x NEMA 5-15R, 4 x NEMA 5-15/20R

VPN: SMART2200RM2U SKU: RSC187198 UPC: 37332150622

  • Protege los equipos contra apagones, caídas de tensión, sobretensiones transitorias y ruido en la línea.
  • Mantiene el equipo en funcionamiento durante las interrupciones para permitir tiempo para guardar archivos y realizar un apagado seguro.
  • El factor de potencia unitario garantiza la máxima potencia posible en cada clasificación de potencia.

Bloque de texto

Descuento por volumen disponible: solicite cotización.

Ver todos los detalles

Recently Viewed

Tripp Lite SmartPro SMART2200RM2U UPS de 2200 VA para montaje en rack - 2200 VA/1

Resumen de información del producto

Tripp Lite SmartPro SMART2200RM2U UPS de 2200 VA para montaje en rack - 2200 VA/1

Acerca del producto

1.95kVA/1.95kW/120V Battery Backup for Distributed IT, Telecom or Enterprise Deployments
This rack-mount line-interactive UPS system provides reliable battery backup and AC power protection against blackouts, brownouts, surges and line noise that can damage your IT equipment or destroy data. The SMART2200RM2U is ideal power management for high-end in-rack networking equipment, including servers, VoIP phones, data storage and PoE switches. Unity power factor ensures the most watts possible at each power rating, so you can connect more equipment.

Reliable, Expandable Battery Backup Keeps You Operational Through Power Outages
The field-replaceable, hot-swappable VRLA battery modules allow you to work through short power failures and give you enough time to safely save files and shut down your system in case of a prolonged blackout. Switchover from line to battery power happens within milliseconds to maintain continuous operation of connected equipment without interruption or rebooting. Extra runtime is available by connecting up to four optional extended battery modules (BP72VRM2U, sold separately).

Optional LX Platform Network Management Card Allows Remote Access 24/7
The WEBCARDLXE network interface (sold separately) enables full remote configuration and management, including load shedding, reboots of connected equipment and safe shutdowns. The IP-based Auto Probe feature ensures continuous network uptime by communicating with other network devices, detecting lost connectivity and automatically rebooting IT equipment. Optional EnviroSense2 modules (E2MT, E2MTDO and E2MTHDI, all sold separately) provide a variety of environmental monitoring and control options.

NEMA Outlets Protect Your Connected Components
One L5-20R and six 5-20R managed outlets provide connected equipment with pure sine wave AC output and allow you to monitor power consumption down to the outlet group level. Power provided by these outlets is filtered to protect connected equipment against damaging surges and line noise. Four 5-20R outlets are split into two independently switchable load banks that let you shed non-critical loads to extend runtime for critical loads. Front and rear cooling fans help protect equipment from overheating.

Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions
AVR protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts. The SMART2200RM2U maintains regulated 120V nominal output during brownouts and overvoltages from 80V to 151V while keeping the battery fully charged and ready to take over in case of power failure.

More from the Manufacturer

  • Protects equipment against blackouts, brownouts, transient surges and line noise
  • Keeps equipment running during outages to allow time for file saves and safe shutdown
  • Unity power factor ensures maximum power possible at each power rating
  • ENERGY STAR 2.0-certified to save electricity, lower costs and protect the environment
  • 2-line front-panel LCD with 10 selectable screens reports detailed UPS and site power info
  • For remote monitor and control, the WEBCARDLXE is required (sold separately). Not compatible with WEBCARDLX.

Especificaciones técnicas

Controls/Indicators
Status Indicators

5 Front Panel Leds:

  • Green Power Led
  • Green Voltage Correction Led
  • 3 Color Battery Charge Led
  • 3 Color Output Load Led
  • Red Battery Warning Led
Display & Graphics
DisplayLCD
Warranty
Additional Warranty Information2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.
Interfaces/Ports
USBYes
Serial PortYes
EPO PortYes
USB (HID Compliant) PortYes
Environmental Conditions
Minimum Operating Temperature32°F (0°C)
Maximum Operating Temperature104°F (40°C)
Maximum Operating Elevation10000 ft (3048000 mm)
Maximum Storage Elevation32808 ft (9999878.40 mm)
Sound Emission (A-Weighted)45 dB(A)
Physical Characteristics
Weight (Approximate)65.30 lb (29619.58 g)
Form FactorRack/Tower
Rack Height2U
Height3.39" (86 mm)
Width17.20" (437 mm)
Depth23.70" (602 mm)
Management
Network ManagementSNMP/Web
AlarmUPS Fault
Remote Shutdown
Power Failure
Overload
Low Battery
UPS StartUp
Battery Information
Battery ChemistryLead Acid
Hot SwappableYes
Backup/Run Time (Half Load)12 Minute
Backup/Run Time (Full Load)4 Minute
Battery CharacteristicsValve-regulated
Replaceable BatteryYes
DC System Voltage72 V DC
Typical Battery Recharge Time4.50 Hour
General Information
Product TypeLine-interactive UPS
Manufacturer Part NumberSMART2200RM2U
Manufacturer Website Addresshttp://www.eaton.com/EatonCom/Markets/NorthAmerica
Packaged Quantity1 Each
ManufacturerEaton Corporation
Product ModelSMART2200RM2U
Product NameSmartPro SMART2200RM2U 1950VA Rack/Tower UPS
Product LineSmartPro
Brand NameTripp Lite series
Miscellaneous
Package Contents
  • SmartPro SMART2200RM2U 1950VA Rack/Tower UPS
  • USB cable
  • DB9 cable
  • Rack-mounting hardware
  • Tower support stands
  • Safety instructions
  • Software IncludedPowerAlert Software
    Certifications & Standards
    • UL1778 (USA)
    • CSA (Canada)
    • NOM (Mexico)
    • FCC Part 15 Category A (EMI)
    Country of OriginChina
    RecycledNo
    Environmentally FriendlyYes
    TAA CompliantYes
    Energy StarYes
    Energy Efficiency CertificationENERGY STAR 2.0
    Environmental ComplianceRestriction of Hazardous Substances (RoHS)
    Power Description
    Input Voltage120 V AC
    Output Voltage110 V AC
    120 V AC
    125 V AC
    100 V AC
    Input Current16.40 A
    Surge Energy Rating380 J
    Waveform TypePure Sine Wave
    Input Voltage Range70 V AC - 153 V AC
    Output Frequency60 Hz
    Input Frequency60 Hz
    Load Capacity (VA)1.95 kVA
    Load Capacity (Watt)1.95 kW
    Output Power Factor1
    Technical Information
    Application/UsageData Storage
    IT Equipment
    Server
    Switch
    Emergency Power OFFYes
    Overload ProtectionYes
    Protection TypeUnder Voltage
    Over Voltage
    Plug/Connector TypeNEMA 5-20P
    Cord Length10 ft (3.05 m)
    PhaseSingle Phase
    Receptacle TypeNEMA 5-20R
    NEMA L5-20R
    EMI/RFI Noise FilterYes
    AVRYes
    Energy SavingGreater than 95% efficiency - GREEN UPS; Individually controllable load banks
    Transfer Time4 ms
    Receptacle Detail1 x NEMA L5-20R
    6 x NEMA 5-20R
