Acerca del producto
Smart-UPS RT is a family of high preformance UPSs for servers, networking equipment, telecommunication systems, industrial and medical equipment, and other mission-critical applications. Smart-UPS RT UPSs are based on the field-proven, industry-leading Smart-UPS functionality, but features double conversion on-line topology, which delivers tight voltage and frequency regulation, zero transfer time to and from battery, and input power factor correction. While offering advanced performance and high availability features, the Smart-UPS RT can be managed using PowerChute software, as well as an array of SmartSlot accessories. Smart-UPS RT provides battery back up to the load through the use of internal batteries. However, an unlimited number of external battery packs can be added to meet desired levels of runtime. All Smart-UPS RTs and battery packs ship in tower configuration, while easily converting to the 19" rack-mount mode with the addition of an APC Rail Kit.
- 1 kVA load capacity - work without any interruption during power outages
- 700 W load capacity - backup power for your valuable electronics
- Prevent critical data loss by staying powered during a blackout with up to 700 W load capacity
- 1 kVA load capacity provides sufficient backup during power failures
- Keep your sensitive devices powered with a backup of up to 10.20 minute at full load
- Up to 10.20 minute runtime on full load to preserve critical data from power shortage interruptions
Especificaciones técnicas
| Controls/Indicators | |
| Status Indicators | LED status display with load and battery bar-graphs and On Line, On Battery, Replace Battery, Overload and Bypass Indicators. |
| Interfaces/Ports | |
| Serial Port | Yes |
| Total Number of Expansion Slots | 1 |
| Environmental Conditions | |
| Thermal Dissipation | 239 BTU/h |
| Maximum Operating Temperature | 122°F (50°C) |
| Sound Emission (A-Weighted) | 50 dB(A) |
| Management | |
| Battery Management | Intelligent Battery Management |
| Alarm | Low Battery |
| Overload | |
| On Battery | |
| Miscellaneous | |
| Additional Information |
|
| Package Contents | |
| Certifications & Standards |
|
| Environmentally Friendly | Yes |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Hot Swappable | Yes |
| Backup/Run Time (Half Load) | 24.40 Minute |
| Backup/Run Time (Full Load) | 10.20 Minute |
| Battery Characteristics | Spill-proof, Maintenance-free |
| Typical Battery Recharge Time | 3 Hour |
| Power Description | |
| Input Voltage | 220 V AC |
| Output Voltage | 230 V AC |
| Surge Energy Rating | 420 J |
| Waveform Type | Sine Wave |
| Load Capacity (VA) | 1 kVA |
| Load Capacity (Watt) | 700 W |
| Physical Characteristics | |
| Weight (Approximate) | 50.60 lb (22951.77 g) |
| Form Factor | Tower |
| Height | 3.35" (85.09 mm) |
| Width | 17" (431.80 mm) |
| Depth | 19" (482.60 mm) |
| Product Color | Black |
| Color Family | Black |
| Technical Information | |
| Bypass Switch | Automatic |
| Emergency Power OFF | Optional |
| Plug/Connector Type | IEC 320-C14 |
| Receptacle Type | IEC 60320 C13 |
| Number of Battery & Surge Outlets | 8 |
| Transfer Time | 0 ns |
| Receptacle Detail | 6 x IEC 60320 C13 |
| 2 | |
| General Information | |
| Product Type | Double Conversion Online UPS |
| Manufacturer Part Number | SURT1000XLI |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Packaged Quantity | 1 Each |
| Manufacturer | Schneider Electric SA |
| Product Name | Smart-UPS RT 1000VA |
| Product Line | Smart-UPS |
| Product Series | RT |
| Brand Name | APC by Schneider Electric |
