Super Micro

Sistema Barebone de servidor Supermicro SuperServer 1028R-TDW - Montaje en rack 1U

Name: Sistema Barebone de servidor Supermicro SuperServer 1028R-TDW - Montaje en rack 1U
Brand: Super Micro
SKU: 83771ZCM
Price: 1897.34 CAD
Availability: OutOfStock

$1,897.34 CAD

~~$2,125.03 CAD~~ $1,897.34 CAD

-10% OFF Agotado

Los gastos de envío se calculan en la pantalla de pago.

Sistema Barebone de Servidor Supermicro SuperServer 1028R-TDW - Montaje en Rack 1U - Zócalo R LGA-2011 - Compatibilidad con 2 Procesadores - Chip Intel C612 Express - 1 TB DDR4 SDRAM DDR4-2133/PC4-17000 - 16 Ranuras de Memoria - Controlador Compatible con Serial ATA/600 RAID - Tarjeta Gráfica AST2400 - Red (RJ-45) - 8 Interfaces SATA - Compatibilidad con Procesadores (Xeon) - 6 Puertos USB 3.0 - 1 x 600 W - 3 Años

VPN:SYS-1028R-TDWSKU:83771ZCM UPC:

Con 6 puertos USB para conectar dispositivos compatibles con USB
Ranura compatible con DDR4 SDRAM: instala memoria que reduce el tiempo de inactividad del procesador y mejora el rendimiento de la computadora
La interfaz Serial ATA/600 proporciona una transferencia de datos rápida y un mayor rendimiento

Bloque de texto

Cantidad

Descuento por volumen disponible: solicite cotización.

Ver todos los detalles

Resumen de información del producto

Sistema Barebone de servidor Supermicro SuperServer 1028R-TDW - Montaje en rack 1U

Acerca del producto

Featuring 6 USB ports to connect USB-compatible devices

DDR4 SDRAM compatible slot - Installs memory that reduces processor's idle time and enhances computer's performance

Serial ATA/600 interface provides quick data transfer and greater throughput

Fast Ethernet port is the ideal solution for extending network connections to conference rooms, labs, lobbies and department workgroups

Experience high performance, built-in security and remote management capabilities with Intel Xeon processor

Especificaciones técnicas

Display & Graphics
Graphics Controller Model	AST2400
Chipset
Chipset Manufacturer	Intel
Chipset Model	C612 Express
Network & Communication
Ethernet Technology	Fast Ethernet
	10 Gigabit Ethernet
Controllers
RAID Levels	0, 1, 5, 10
Controller Type	Serial ATA/600
RAID Supported	Yes
Miscellaneous
Package Contents	SuperServer 1028R-TDW (Black) 1 x Super X10DDW-i Motherboard 1 x 1U Chassis 1 x BPN-SAS-113TQ-O-P 1 x 4 pin to 4 pin fan extension cord, for PWM fan. 23cm. 24AWG 2 x RA IPASS TO 4 SATA, 70/70/75/75cm w/75cm SB, 30AWG,RoHS/REACH 1 x RSC-R1UW-2E16-O-P 1 x RSC-R1UW-E8R-O-P 2 x 1U Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB 1 x 1U 600W Multi Output Power Supply PMbus 1 x SC815/113/116 Intel DP X9, X8 PC air shroud,1368x13/12x13MB 1 x FRONT CTL CABLE 20 PIN TO 20 PIN W/TUBE,70CM,PBF. 28AWG 1 x NEMA5-15P to C13 US power cord 16AWG 6ft, PBF (default for high watt) 1 x Black DVD dummy tray support 1x2.5 HDD for SC113,815,825,836 4 x 40x56 4Pin PWM, Primary for SC815, Secondary for SC818, 825M 8 x Black gen 3rd hot-swap 2.5inch HDD tray 1set Inner rail, extension, long, screw type 1set Outer rail, screw type, 25.6\" to 33.05\" 1set Inner rail, front, short, screw type
Certifications & Standards	ACPI 1.0 ACPI 2.0 ACPI 3.0 ACPI 4.0
Environmentally Friendly	Yes
I/O Expansions
Number of Total Expansion Bays	8
Number of PCI Express x8 Slots	2
Number of PCI Express Slots	1
Total Number of Expansion Slots	3
Memory
Maximum Memory Supported	1 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2133/PC4-17000
Total Number of Memory Slots	16
Power Description
Input Voltage	120 V AC
	230 V AC
Number of Power Supplies Installed	1
Maximum Power Supply Wattage	600 W
Interfaces/Ports
Number of SATA Interfaces	8
VGA	Yes
Network (RJ-45)	Yes
Total Number of USB Ports	6
Number of USB 3.0 Ports	6
Processor
Processor Supported	Xeon
Processor Socket	Socket R LGA-2011
64-bit Processing	Yes
QuickPath Interconnect	9.60 GT/s
Number of Processors Supported	2
QuickPath Interconnect Supported	Yes
Physical Characteristics
Form Factor	Rack-mountable
Rack Height	1U
Height	1.70" (43.18 mm)
Width	17.20" (436.88 mm)
Depth	25.60" (650.24 mm)
Product Color	Black
Color Family	Black
General Information
Product Type	Server Barebone System
Manufacturer Part Number	SYS-1028R-TDW
Manufacturer Website Address	http://www.supermicro.com
Manufacturer	Supermicro Computer, Inc
Product Model	1028R-TDW
Product Name	SuperServer 1028R-TDW (Black)
Product Line	SuperServer
Brand Name	Supermicro
