| Display & Graphics |
| Graphics Controller Model | AST2500 |
| Miscellaneous |
| Country of Origin | United States |
| Network & Communication |
| Ethernet Technology | Gigabit Ethernet |
| Chipset |
| Chipset Manufacturer | Intel |
| Chipset Model | C621 |
| Controllers |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| Interfaces/Ports |
| Number of SATA Interfaces | 10 |
| Total Number of USB Ports | 8 |
| Number of USB 3.0 Ports | 6 |
| Memory |
| Maximum Memory Supported | 2 TB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-2666/PC4-21300 |
| Total Number of Memory Slots | 16 |
| Power Description |
| Input Voltage | 230 V AC |
| 120 V AC |
| Number of Power Supplies Installed | 1 |
| Maximum Power Supply Wattage | 1.20 kW |
| Processor |
| Processor Supported | Xeon |
| Processor Socket | Socket P LGA-3647 |
| 64-bit Processing | Yes |
| Number of Processors Supported | 2 |
| I/O Expansions |
| "Number of External 5.25"" Bays" | 3 |
| Number of Total Expansion Bays | 11 |
| "Number of 3.5"" Bays" | 8 |
| Number of PCI Express x8 Slots | 2 |
| Number of PCI Express x16 Slots | 4 |
| Total Number of Expansion Slots | 6 |
| Physical Characteristics |
| Form Factor | Tower |
| Rack Height | 4U |
| Height | 17.80" (452.12 mm) |
| Width | 7" (177.80 mm) |
| Depth | 25.50" (647.70 mm) |
| Product Color | Black |
| Color Family | Black |
| General Information |
| Product Type | Server Barebone System |
| Manufacturer Part Number | SYS-7049A-T |
| Manufacturer Website Address | http://www.supermicro.com |
| Manufacturer | Supermicro Computer, Inc |
| Product Model | 7049A-T |
| Product Name | SuperWorkstation 7049A-T |
| Product Line | SuperWorkstation |
| Brand Name | Supermicro |
