Acerca del producto
TL-SG116P is an unmanaged switch with 16 Gigabit ports that requires no configuration and provides 16 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af/at compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.
Power Over Ethernet
16 RJ45 ports of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af/at compliant Powered Devices (PDs).
Overload Arrangement
TL-SG116P has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is ? 120 W, a priority will be arranged among the PoE ports, then the system will cut off the power of the lowest-priority port.
- Gigabit Ethernet port for ultra-fast network speeds
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Can work as layer 3 routing for scalable network design
- Supports layer 3 switching for enhanced performance and usability
- The unmanaged switch provides a quick, easy and cost-saving way to add wired networking to your home, office or small business; no intervention needed
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Quickly and easily set up a wired network with 16 networking ports
Especificaciones técnicas
| Management & Protocols | |
| Manageable | No |
| Technical Information | |
| Features | Fanless |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Total Number of Network Ports | 16 |
| Port/Expansion Slot Details | 16 x Gigabit Ethernet PoE+ |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T |
| Ethernet Technology | Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| Miscellaneous | |
| Application/Usage | IP Camera |
| Network | |
| IP Phone | |
| Physical Characteristics | |
| Form Factor | Desktop |
| Wall Mountable | |
| Height | 1" (25.40 mm) |
| Width | 11.26" (286 mm) |
| Depth | 4.40" (111.70 mm) |
| Product Color | Black |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | TLSG116P |
| Manufacturer Website Address | http://www.tp-link.com |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Product Model | TL-SG116P |
| Product Name | 16-Port Gigabit Desktop Switch with 16-Port PoE+ |
| Brand Name | TP-Link |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.3u |
| IEEE 802.3x | |
| IEEE 802.3i | |
| IEEE 802.3at | |
| IEEE 802.3af | |
| IEEE 802.3z | |
| Power Description | |
| Input Voltage | 230 V AC |
| 120 V AC | |
| Power Source | Power Supply |
| Frequency | 50 Hz |
| 60 Hz | |
| Power Consumption | 144.28 W |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 120 W |
