Acerca del producto
TRENDnet’s 1-Port Serial to IP Ethernet Converter, model TU-S9E, allows users to easily and remotely manage an RS-232 serial device within the local network. With a flat and compact size, the RS-232 to Ethernet converter is ideal for cabinet installations where space can be limited. The rugged housing design is suited for most installation environments, including harsh and industrial environments. Setup is easy and the included software offers simple configuration for customizing the RS-232 to Ethernet converter to seamlessly fit your network application.
TRENDnet’s 1-Port Serial to IP Ethernet Converter Features:
- Remotely connect and configure your serial device over your local network
- Easy setup with software or web browser
- Supports virtual serial port, DHCP server and TFTP
- Rugged and durable metal housing
- Software utility included
- NDAA compliant
TRENDnet’s 1-Port Serial to IP Ethernet Converter Specifications:
- Interface:
- 1 x 10/100Mbps port
- 1 x RS-232 (9-pin) male
- Data Rate:
- RS-232 port: Up to 921.6Kbps
- Ethernet port: Up to 100Mbps
- Operating Temperature: 0° – 40° C (32° – 104° F)
- Operating Humidity: Max. 95% non-condensing
- Pinout:
Pin 1 2 3 4 5 6 7 8 9 Signal DCD RxD TxD DTR GND DSR RTS CTS RI - Power:
- Input: 100 – 240V AC, 50/60Hz, 0.25A
- Output: 5V DC, 1A external power adapter
- Max. consumption: 1.1W
- Compatibility (Utility): Windows ™
- Dimensions: 62 x 42 x 23mm (2.44 x 1.65 x 0.9 in.)
- Weight: 102g (3.6 oz.)
- Certifications:
- CE
- FCC
- Warranty: 2 Years
Especificaciones técnicas
TRENDnet’s 1-Port Serial to IP Ethernet Converter, model TU-S9E, allows users to easily and remotely manage an RS-232 serial device within the local network. With a flat and compact size, the RS-232 to Ethernet converter is ideal for cabinet installations where space can be limited. The rugged housing design is suited for most installation environments, including harsh and industrial environments. Setup is easy and the included software offers simple configuration for customizing the RS-232 to Ethernet converter to seamlessly fit your network application.
TRENDnet’s 1-Port Serial to IP Ethernet Converter Features:
- Remotely connect and configure your serial device over your local network
- Easy setup with software or web browser
- Supports virtual serial port, DHCP server and TFTP
- Rugged and durable metal housing
- Software utility included
- NDAA compliant
TRENDnet’s 1-Port Serial to IP Ethernet Converter Specifications:
- Interface:
- 1 x 10/100Mbps port
- 1 x RS-232 (9-pin) male
- Data Rate:
- RS-232 port: Up to 921.6Kbps
- Ethernet port: Up to 100Mbps
- Operating Temperature: 0° – 40° C (32° – 104° F)
- Operating Humidity: Max. 95% non-condensing
- Pinout:
Pin 1 2 3 4 5 6 7 8 9 Signal DCD RxD TxD DTR GND DSR RTS CTS RI - Power:
- Input: 100 – 240V AC, 50/60Hz, 0.25A
- Output: 5V DC, 1A external power adapter
- Max. consumption: 1.1W
- Compatibility (Utility): Windows ™
- Dimensions: 62 x 42 x 23mm (2.44 x 1.65 x 0.9 in.)
- Weight: 102g (3.6 oz.)
- Certifications:
- CE
- FCC
- Warranty: 2 Years
