Acerca del producto
- Embedded in Intel Bay Trail J1900/Skylake Core i3/i5 processor
- Compact design with 45mm in height
- Easy/quick installation for additional peripherals and expanded modular
- Support 1 x 2.5" SATA HDD Bay and 1 mSATA
- Multiple IO ports is suitable for variety of applications.
- Lockable DC jack design
- Support wall/VESA mount
- Supports WISE-PaaS/RMM and Embedded Software APIs
Especificaciones técnicas
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| LAN Model | RTL8111E |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Maximum Power Supply Wattage | 60 W |
| Display & Graphics | |
| Graphics Controller Manufacturer | Intel |
| Graphics Controller Model | HD Graphics |
| Graphics Memory Technology | DDR3L SDRAM |
| Graphics Memory Accessibility | Shared |
| Memory | |
| Maximum Memory Supported | 8 GB |
| Standard Memory | No |
| Memory Technology | DDR3L SDRAM |
| Total Number of Memory Slots | 1 |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Interfaces/Ports | |
| HDMI | Yes |
| VGA | Yes |
| Total Number of USB Ports | 5 |
| Number of USB 2.0 Ports (Front) | 1 |
| Number of USB 2.0 Ports (Rear) | 4 |
| Physical Characteristics | |
| Weight (Approximate) | 4.41 lb (2000 g) |
| Form Factor | Box PC |
| Height | 1.77" (45 mm) |
| Width | 7.28" (185 mm) |
| Depth | 9.65" (245 mm) |
| Processor | |
| Processor Speed | 2 GHz |
| Processor Type | Celeron |
| Processor Model | J1900 |
| Processor Manufacturer | Intel |
| Maximum Turbo Speed | 2.42 GHz |
| General Information | |
| Product Type | Desktop Computer |
| Manufacturer Part Number | UBX-310D-L0U0E |
| Manufacturer Website Address | http://www.advantech.com |
| Manufacturer | Advantech Co., Ltd |
| Product Model | UBX-310 |
| Product Name | UBX-310 Desktop Computer |
| Brand Name | Advantech |
