Acerca del producto
Delivering performance, versatility and density without compromise, the Cisco UCS B200 M5 Blade Server addresses the broadest set of workloads, from IT and web infrastructure through distributed database.
The enterprise-class Cisco UCS B200 M5 blade server extends the capabilities of Cisco's Unified Computing System portfolio in a half-width blade form factor. The Cisco UCS B200 M5 harnesses the power of the latest Intel® Xeon® processor scalable family CPUs with up to 3072 GB of RAM (using 128 GB DIMMs), two solid-state drives (SSDs) or hard disk drives (HDDs), and up to 80 Gbps throughput connectivity.
The enterprise-class Cisco UCS B200 M5 blade server extends the capabilities of Cisco's Unified Computing System portfolio in a half-width blade form factor. The Cisco UCS B200 M5 harnesses the power of the latest Intel® Xeon® processor scalable family CPUs with up to 3072 GB of RAM (using 128 GB DIMMs), two solid-state drives (SSDs) or hard disk drives (HDDs), and up to 80 Gbps throughput connectivity.
- 40 Gigabit Ethernet for efficient data transfer and fast connectivity
- RAID provides data reliability, fault tolerance and improves overall performance
- With 384 GB memory, run as many programs as you want without losing performance
Especificaciones técnicas
| Network & Communication | |
| Ethernet Technology | 40 Gigabit Ethernet |
| Warranty | |
| Additional Warranty Information |
|
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C621 |
| Controllers | |
| Controller Type | Serial Attached SCSI (SAS) |
| Serial ATA | |
| RAID Supported | Yes |
| Display & Graphics | |
| Graphics Controller Model | G200e |
| Graphics Memory Capacity | 16 MB |
| Graphics Memory Technology | DDR4 SDRAM |
| Operating System | |
| Operating System Supported | Red Hat Enterprise Linux |
| Windows Server 2019 Standard | |
| Windows Server 2019 Datacenter | |
| SuSE Linux Enterprise Server | |
| Physical Characteristics | |
| Weight (Approximate) | 15.98 lb (7250 g) |
| Form Factor | Blade |
| Height | 1.95" (49.53 mm) |
| Width | 8" (203.20 mm) |
| Depth | 24.40" (619.76 mm) |
| Interfaces/Ports | |
| Number of Network (RJ-45) Ports | 2 |
| Network (RJ-45) | Yes |
| Remote Management | Yes |
| Total Number of USB Ports | 1 |
| Number of USB 3.0 Ports | 1 |
| Remote Management Controller | Cisco Integrated Management Controller (CIMC) |
| General Information | |
| Product Type | Server |
| Manufacturer Part Number | UCSSPB200M5CST |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Name | UCS B200 M5 Server |
| Product Series | B200 M5 |
| Brand Name | Cisco |
| Memory | |
| Error Checking | ECC |
| Maximum Memory Supported | 3 TB |
| Signal Processing | Registered (Buffered) |
| Standard Memory | 384 GB |
| Memory Technology | DDR4 SDRAM |
| Number of Occupied Memory Slots | 12 |
| Intel Optane Memory Ready | Yes |
| Total Number of Memory Slots | 24 |
| Processor | |
| Cache | 27.50 MB |
| Processor Speed | 2.10 GHz |
| Processor Type | Xeon Gold |
| Processor Model | 5218R |
| Processor Core | Icosa-core (20 Core) |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 2 |
| Processor Generation | 2nd Gen |
