Acerca del producto
Especificaciones técnicas
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C621 |
| Controllers | |
| Controller Type | 12Gb/s SAS |
| RAID Supported | Yes |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Gigabit Ethernet | |
| Display & Graphics | |
| Graphics Controller Manufacturer | Matrox |
| Graphics Controller Model | G200e |
| Graphics Memory Capacity | 16 MB |
| Memory | |
| Error Checking | ECC |
| Maximum Memory Supported | 3 TB |
| Standard Memory | 64 GB |
| Memory Technology | DDR4 SDRAM |
| Number of Occupied Memory Slots | 2 |
| Total Number of Memory Slots | 24 |
| Operating System | |
| Operating System Supported | Red Hat Enterprise Linux |
| Windows Server 2022 Standard | |
| Windows Server 2022 Datacenter | |
| Windows Server 2019 Standard | |
| Windows Server 2019 Datacenter | |
| SuSE Linux Enterprise Server | |
| Physical Characteristics | |
| Weight (Approximate) | 59.97 lb (27200 g) |
| Form Factor | Rack |
| Rack Height | 1U |
| Height | 1.70" (43.18 mm) |
| Width | 18.98" (482.09 mm) |
| Depth | 30.98" (786.89 mm) |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Power Source | Power Supply |
| Plug/Connector Type | C13 |
| Number of Power Supplies Supported | 2 |
| Hot Swappable Power Supply | Yes |
| General Information | |
| Product Type | Server |
| Manufacturer Part Number | UCS-SPRC220M5C2-RF |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Name | UCS C220 M5 Server |
| Product Series | C220 M5 |
| Brand Name | Cisco |
| Product Condition | Refurbished |
| Interfaces/Ports | |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Network (RJ-45) | Yes |
| Remote Management | Yes |
| Total Number of USB Ports | 2 |
| Number of USB 3.0 Ports | 2 |
| Number of VGA Ports | 1 |
| Remote Management Controller | Baseboard Management Controller (BMC) |
| I/O Expansions | |
| Riser Card | Riser 1 (controlled by CPU 1): One full-height profile, 3/4-length slot with x24 connector and x16 lane. |
| Riser 2 (controlled by CPU 2): One half-height profile, half-length slot with x24 connector and x16 lane. | |
| "Number of Internal 2.5"" Bays" | 10 |
| Number of Total Expansion Bays | 10 |
| Total Number of Expansion Slots | 2 |
| Hot Swappable Bays | Yes |
| Number of SFF Bays | 10 |
| PCI Express Details | One full-height profile, 3/4-length slot with x24 connector and x16 lane. |
| One half-height profile, half-length slot with x24 connector and x16 lane. | |
| Processor | |
| Cache | 22 MB |
| Processor Speed | 2.10 GHz |
| Processor Type | Xeon Gold |
| Processor Model | 6130 |
| Processor Core | Hexadeca-core (16 Core) |
| Processor Manufacturer | Intel |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 2 |
| Processor Generation | 2nd Gen |
