Acerca del producto
Delivering performance, versatility and density without compromise, the Cisco UCS B200 M6 Blade Server addresses the broadest set of workloads, from IT and web infrastructure through distributed database.
The enterprise-class Cisco UCS B200 M6 blade server extends the capabilities of Cisco's Unified Computing System portfolio in a half-width blade form factor. The Cisco UCS B200 M6 harnesses the power of the latest 3rd Gen Intel® Xeon® Scalable Processors (Ice Lake) with:
The enterprise-class Cisco UCS B200 M6 blade server extends the capabilities of Cisco's Unified Computing System portfolio in a half-width blade form factor. The Cisco UCS B200 M6 harnesses the power of the latest 3rd Gen Intel® Xeon® Scalable Processors (Ice Lake) with:
- Up to 4 TB of RAM per CPU (using 16 x 256 GB DRAMs) or up to 6 TB per CPU (using 8 x 256 GB DRAMs and 8 x 512 GB Intel® Optane™ Persistent Memory Modules (PMEMs))
- Two solid-state drives (SSDs), or
- Two PCIE NVMe drives, or
- Mini storage carrier with M.2 SATA drives
- Up to 80 Gbps throughput connectivity.
- DDR4 SDRAM compatible slot - Installs memory that reduces processor's idle time and enhances computer's performance
- 12Gb/s SAS interface for high speed and reliability
- Speed up workflows and increase productivity by sharing the organizational resources via Ethernet connectivity
- Perform computational tasks effectively accrediting the Xeon Bronze processor
Especificaciones técnicas
| I/O Expansions | |
| Number of Total Expansion Bays | 2 |
| Network & Communication | |
| Ethernet Technology | Ethernet |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C621A |
| Display & Graphics | |
| Graphics Controller Model | G200e |
| Graphics Memory Capacity | 8 MB |
| Storage | |
| Supported Storage Drive Interfaces | SAS-3 |
| Serial ATA | |
| Controllers | |
| Controller Type | 12Gb/s SAS |
| Serial ATA | |
| RAID Supported | Yes |
| Memory | |
| Maximum Memory Supported | 12 TB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-2666/PC4-21300 |
| Intel Optane Memory Ready | Yes |
| Total Number of Memory Slots | 32 |
| Physical Characteristics | |
| Weight (Approximate) | 10.01 lb (4540 g) |
| Form Factor | Blade |
| Height | 1.95" (49.53 mm) |
| Width | 8.35" (212.09 mm) |
| Depth | 24.40" (619.76 mm) |
| Processor | |
| Processor Supported | Xeon Bronze |
| Xeon Gold | |
| Xeon Platinum | |
| Xeon Silver | |
| 64-bit Processing | Yes |
| Number of Processors Supported | 2 |
| General Information | |
| Product Type | Barebone System |
| Manufacturer Part Number | UCSB-B200-M6-U |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Model | UCSB-B200-M6-U |
| Product Name | UCS B200 M6 Barebone System |
| Product Series | B200 M6 |
| Brand Name | Cisco |
