Acerca del producto
The Vertiv Geist Monitored RPDU VP4UV0A1 is a 16A/20A, 120V/208V/230V, 0U, horizontal rack power distribution unit with input power monitoring and outlet level switching. It has (36) IEC C13 and (6) IEC C19 outlets, a C20 inlet, and 1.9kW/3.3kW/3.6kW of power capacity. This device allows you to remotely turn off receptacles to avoid accidental overloads and power cycle equipment to reboot unresponsive critical IT equipment. It is integrated with the Vertiv Geist Next Generation IMD which displays power data via its 128x128 high-visibility touchscreen LCD. The touchscreen interface allows users to provision their rPDU without a need for a network connection. This includes a redundant power-sharing port that connects two IMDs in the rack and provides backup power in case of power loss. Enhanced security with secure boot is added in the device to help ensure data and operations are protected. The units are CE Marked and individually tested for functionality and reliability.
- Electric power fitted to racks of computers and networking equipment within a data center
- PDU allows power to be more efficiently distributed and controlled
- With monitored PDU, you can remotely monitor single-or three-phase voltage easily
Especificaciones técnicas
| Environmental Conditions | |
| Maximum Operating Temperature | 140°F (60°C) |
| Warranty | |
| Additional Warranty Information | 5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years |
| Management | |
| Management |
|
| Remote Outlet Switching | No |
| Interfaces/Ports | |
| USB | Yes |
| Network (RJ-45) | Yes |
| Modem (RJ-11) | No |
| Serial Port | Yes |
| Modem (RJ-12) | Yes |
| Modem (RJ-22) | No |
| Miscellaneous | |
| Application/Usage | IT Equipment |
| Package Contents |
|
| Certifications & Standards |
|
| TAA Compliant | Yes |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS) |
| Restriction of Hazardous Substances (RoHS) | |
| Power Description | |
| Input Voltage | 230 V AC |
| Input Current | 20 A |
| Input Voltage Range | 100 V AC - 240 V AC |
| Input Frequency | 60 Hz |
| Output Voltage Range | 100 V AC - 240 V AC |
| Power Rating (Watt) | 3.60 kW |
| General Information | |
| Product Type | PDU |
| Manufacturer Part Number | VP4UV0A1 |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Manufacturer | Vertiv |
| Product Model | MU05M4W0-42PZ67-2C20A9A00-S |
| Product Name | Monitored VP4UV0A1 PDU |
| Product Line | Geist Upgradeable |
| Product Series | G |
| Brand Name | Vertiv Geist |
| Physical Characteristics | |
| Weight (Approximate) | 16 lb (7257.48 g) |
| Length | 70" (1778 mm) |
| Mount Type | Rack-mountable |
| Rack Height | 0U |
| Cord Length | 10 ft (3.05 m) |
| Width | 2" (50.80 mm) |
| Depth | 2" (50.80 mm) |
| Mounting Orientation | Vertical |
| Product Color | Black Powder Coat |
| Color Family | Black |
| Technical Information | |
| Features | Touch Screen Display |
| LCD Display | |
| Plug/Connector Type | IEC 60320 C20 |
| Phase | Single Phase |
| Receptacle Type | U-Lock IEC 60320 C19 |
| U-Lock IEC 60320 C13 | |
| Load Capacity (Watt) | 3.60 kW |
| PDU Type | Monitored |
| Receptacle Detail | 6 x U-Lock IEC 60320 C19 |
| 36 x U-Lock IEC 60320 C13 | |
| Plug/Connector Detail | 1 x IEC 60320 C20 |
