Acerca del producto
The X82R Series HDCVI DVR offers 4K recording on each HDCVI channel and a host of advanced features and functions. The X82R takes advantage of HDCVI technology for easy integration into existing video security systems while leveraging existing networks, cabling, and cameras. Penta-brid access technology seamlessly records video from HDCVI, AHD, TVI, CVBS, and IP sources simultaneously, plus the DVR delivers 4K resolution on each HDCVI or IP channel. This recorder is the ideal solution for actively monitoring retail stores, personal property and homes.
WizSense Series devices combine Dahua’s powerful Analytics+ with an intuitive and easy to use interface. WizSense devices offer Smart Motion Detection and Perimeter Protection functions that focus on human and vehicular images and ignore irrelevant images to capture important video while reducing false alarms. WizSense Series devices provide powerful general security for small to medium size businesses at a sensible price.
Dahua X82R3N4 16CH Analytics+ Penta-brid XVR H.265 4K Pro 1U 2 SATA Bays, 4TB Features:
- 4K at 15 fps Recording Resolution on All HDCVI Channels
- Available with a 4 TB, 6 TB, 8 TB, or 10 TB Pre-installed Hard Drive
- Dual-stream Video Recording
- AI Coding Technology for High-quality Human/Vehicle Video
- Auto-detection and Auto-configuration of Video Inputs
- 16 + 16 IP Camera Channels, each channel up to 8 MP
- Maximum 128 Mbps Incoming Bandwidth
- Perimeter Protection and Smart Motion Detection (SMD)
- Long-distance Video Transmission
- Spot Output (HDMI or VGA Output)
- Five-year Warranty
Dahua X82R3N4 16CH Analytics+ Penta-brid XVR H.265 4K Pro 1U 2 SATA Bays, 4TB Specifications:
General:
- Model: X82R3N4
- Channels: 16
- Compression: H.265+/H.265/H.264+/H.264
- Resolution: Up to 4K (3840 x 2160)
- Operating System: Embedded Linux
Video:
- Input: 16 BNC (Analog HD/Analog)
- Output: HDMI, VGA
- Audio: 1 RCA Input, 1 RCA Output
- Audio Compression: G.711u/G.711a
- Two-Way Audio: Support
Recording:
- Recording Resolution: 4K, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, etc.
- Recording Mode: Manual, Schedule (Regular, Continuous), Motion Detection, Alarm, Analytics
- Recording Interval: 1-120 minutes (default: 60 minutes)
- Pre-Recording: Up to 30 seconds
- Post-Recording: Up to 300 seconds
- Playback: 1-16 channels simultaneous playback
- Search Mode: Time/Date, Alarm, MD & Exact Search (accurate to the second)
Storage:
- Internal HDD: 2 SATA ports, up to 12TB (2 x 6TB)
- External HDD: 1 eSATA port
- Backup: USB devices, network backup
Network:
- Ethernet: RJ-45 port (10/100/1000Mbps)
- Network Protocols: HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, SNMP, IP Search (Support Dahua IP camera, DVR, NVS, etc.)
- Max. User Access: 128 users
Mobile App:
- Compatibility: iOS, Android
- Mobile Viewing: Live view, playback, PTZ control, and more
Other Features:
- P2P: Yes (Dahua P2P)
- Alarm Input/Output: 16/6
- RS485: 1 port, for PTZ control
- USB: 2 USB ports (1 x USB 2.0, 1 x USB 3.0)
- Power Supply: DC12V/4A
- Power Consumption: <10W (without HDD)
Dimensions and Weight:
- Dimensions (W x D x H): 375mm x 281.5mm x 56mm (14.76"" x 11.08"" x 2.20"")
- Weight: 1.6kg (3.53lbs)
Especificaciones técnicas
The X82R Series HDCVI DVR offers 4K recording on each HDCVI channel and a host of advanced features and functions. The X82R takes advantage of HDCVI technology for easy integration into existing video security systems while leveraging existing networks, cabling, and cameras. Penta-brid access technology seamlessly records video from HDCVI, AHD, TVI, CVBS, and IP sources simultaneously, plus the DVR delivers 4K resolution on each HDCVI or IP channel. This recorder is the ideal solution for actively monitoring retail stores, personal property and homes.
WizSense Series devices combine Dahua’s powerful Analytics+ with an intuitive and easy to use interface. WizSense devices offer Smart Motion Detection and Perimeter Protection functions that focus on human and vehicular images and ignore irrelevant images to capture important video while reducing false alarms. WizSense Series devices provide powerful general security for small to medium size businesses at a sensible price.
Dahua X82R3N4 16CH Analytics+ Penta-brid XVR H.265 4K Pro 1U 2 SATA Bays, 4TB Features:
- 4K at 15 fps Recording Resolution on All HDCVI Channels
- Available with a 4 TB, 6 TB, 8 TB, or 10 TB Pre-installed Hard Drive
- Dual-stream Video Recording
- AI Coding Technology for High-quality Human/Vehicle Video
- Auto-detection and Auto-configuration of Video Inputs
- 16 + 16 IP Camera Channels, each channel up to 8 MP
- Maximum 128 Mbps Incoming Bandwidth
- Perimeter Protection and Smart Motion Detection (SMD)
- Long-distance Video Transmission
- Spot Output (HDMI or VGA Output)
- Five-year Warranty
Dahua X82R3N4 16CH Analytics+ Penta-brid XVR H.265 4K Pro 1U 2 SATA Bays, 4TB Specifications:
General:
- Model: X82R3N4
- Channels: 16
- Compression: H.265+/H.265/H.264+/H.264
- Resolution: Up to 4K (3840 x 2160)
- Operating System: Embedded Linux
Video:
- Input: 16 BNC (Analog HD/Analog)
- Output: HDMI, VGA
- Audio: 1 RCA Input, 1 RCA Output
- Audio Compression: G.711u/G.711a
- Two-Way Audio: Support
Recording:
- Recording Resolution: 4K, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, etc.
- Recording Mode: Manual, Schedule (Regular, Continuous), Motion Detection, Alarm, Analytics
- Recording Interval: 1-120 minutes (default: 60 minutes)
- Pre-Recording: Up to 30 seconds
- Post-Recording: Up to 300 seconds
- Playback: 1-16 channels simultaneous playback
- Search Mode: Time/Date, Alarm, MD & Exact Search (accurate to the second)
Storage:
- Internal HDD: 2 SATA ports, up to 12TB (2 x 6TB)
- External HDD: 1 eSATA port
- Backup: USB devices, network backup
Network:
- Ethernet: RJ-45 port (10/100/1000Mbps)
- Network Protocols: HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, SNMP, IP Search (Support Dahua IP camera, DVR, NVS, etc.)
- Max. User Access: 128 users
Mobile App:
- Compatibility: iOS, Android
- Mobile Viewing: Live view, playback, PTZ control, and more
Other Features:
- P2P: Yes (Dahua P2P)
- Alarm Input/Output: 16/6
- RS485: 1 port, for PTZ control
- USB: 2 USB ports (1 x USB 2.0, 1 x USB 3.0)
- Power Supply: DC12V/4A
- Power Consumption: <10W (without HDD)
Dimensions and Weight:
- Dimensions (W x D x H): 375mm x 281.5mm x 56mm (14.76"" x 11.08"" x 2.20"")
- Weight: 1.6kg (3.53lbs)
